Engine Cylinder Liner 1979322 197-9322 2W6000 2W-6000 3406 3408 3412
Product Description:
What is a cylinder liner?
It is a cylinder that is fitted to the engine block to form the cylinder, and is one critical function part that forms the engine interior.
In Japan they are usually called Cylinder Liners, but some countries (companies) call them Cylinder Sleeves.
What material is used in cylinder liner?
Cylinder liners are generally made of closed grained pearlitic cast iron, nickel CI, nickel- chrome CI, cast steel and forged alloy steel. The inner surface of the liner is heat treated to obtain a hard and smooth surface.
Features:
What are the main functions of cylinder liner?
The cylinder liner acts as inner wall of the cylinder and forms a sliding surface for the piston rings while retaining the lubracant within. The most important function of cylinder liners is the excellent characteristics as sliding surface.
What are the 3 main types of cylinder liners?
Three basic types of liners are used: hot, dry and finned. The purpose of each type is to protect the piston from heat and impurities using slightly different methods. Cylinder liners are expensive, precisely manufactured products and are primarily purchased from specialty shops.
Technical Parameters:
| Model | 3406 3408 3412 |
| Product Name | Cylinder Liner Cylinder Sleeve |
| Part number | 1979322 197-9322 2W6000 2W-6000 |
| Material | Iron |
| Weight | 8.4 kg |
| Diameter | 137mm |
| Size | 137.16*165*274.1mm |
| Application: | Forklift, Tractor, excavator, |
| Single package size: | 17.5X17.5X30 cm |
Applications:
What are the main functions of cylinder liner?
The cylinder liner acts as inner wall of the cylinder and forms a sliding surface for the piston rings while retaining the lubracant within. The most important function of cylinder liners is the excellent characteristics as sliding surface.
Photos:
More products:
| MODEL | PART NO. | SIZE:(in'out'total) |
| 4D92 | 6140-21-2211 | |
| 4D94 | 6144-21-2211 | |
| 4D95 | 6207-21-2110 | Φ94.2*Φ98*180 |
| S4D95 | 6207-21-2121 | Φ94.2*Φ98*180 |
| 6D95 | 6207-21-2110 | Φ95*Φ98*180 |
| 6D102 | 6736-29-2140 | Φ102*Φ105*200 |
| S4D105 | 6130-22-2213 | Φ105*Φ127*228 |
| S6D105 | 6136-21-2210 | Φ105*Φ127*223 |
| S6D110 | 6138-21-2210 | |
| 6D107 | | Φ106*Φ110*203 |
| S6D108.F | 6222-21-2210 | 108*111.3*219.5 |
| 4D120 | 6110-21-2212 | |
| 4D130 | 6115-21-2211 | |
| S6D110 | 6138-21-2210 | Φ110*Φ115*225 |
| S6D125 | 6150-21-2221 | Φ125*Φ153*256 |
| S6D140 | 6211-21-2210 | |
| S6D155 | 6128-21-2215 | Φ155*Φ184*327 |
| S6D170 | 6162-23-2210 | |
| D6D | | Φ97*Φ101*104.8 |
| D6D+ | | Φ97*Φ102*104.8 |
| D6D.F | | Φ98*Φ101*104.8 |
| D6E | | Φ97*Φ101*188 |
| D6E+ | | Φ97*Φ102*188 |
| D6E,F | | Φ98*Φ101*188 |
